| HS code | 8515809090 | Equipment size | 1990*1100*940 mm |
| Equipment weight | 874.5kg | Voltage | AC 380V 50Hz |
| Power | 13000W | Operating frequency | 20KHz |
| Core Parts | Generator, Transducer, Amplifier（ultrasonic booster）, Welding Horn | Welding Wire Harness Range | <6 mm Copper;<8mm Aluminium |
| Production Efficiency | 120-150pcs/H | Air Pressure | >0.5 MPa |
HMS-D02N & HMS-D02GN ultrasonic wire welder for copper & aluminum harness mass production with yield above 99.9%. Two models cover wide wire cross-section range. Equipped with intelligent control system, MES connection, recipe storage and welding error prevention, perfectly meeting high-standard automatic production for automotive & new energy harness.
HMS-D02N Ultrasonic Torsional Welding Machine |
HMS-D03 Ultrasonic Terminal Welding Machine |
HMS-D02G Ultrasonic Terminal Welding Machine |
<6 mm Copper;<8mm Aluminium |
Copper wire 16mm² -120mm²;Aluminum wire 16mm² -150mm² |
Copper wire 16mm² -120mm²;Aluminum wire 16mm² -150mm² |
20KHz |
20KHz |
20KHz |
AC 380V 50Hz |
AC 380V 50Hz |
AC 380V 50Hz |
874.5kg |
944kg |
944kg |
1990*1100*940 mm |
2060*1650*1300mm |
2060*1650*1300mm |
13000W |
12000W |
13000W |
